Curved belt conveyors

The new generation of 60 C curved belt conveyor has a drive connection via an embedded transmission. This improves installation dimensions and provides the ability to change belt speed to change gear ratio.

Curved belt conveyors are mainly designed to transport piece goods of various properties, especially where the position of the product is to be maintained when the flow direction is changed and the building space is optimized. They are mainly used for installation in larger transport units or, production and assembly lines. Unlike curves with a modular belt or a chain link, the belt curve have no entry and exit straight section.


Curved belt conveyors

Pásová dopravníková zatáčka 60C Pásová dopravníková zatáčka 60C - výkres

Standard parameters
Internal radius of cover Rk 405 – 3 000 mm
Minimum internal radius of ribbon Ri 200 mm
Conveyor load 50 kg/m; 100 kg/conveyor
Drive 3 x 230 – 400 V (1 x 230 V)
Speed measured in the belt axis * 3 - 30 m/min
Transport belt PVC, PU, textile
Operating temperature 10 – 80 °C
Drum diameter 62 mm
* Speed control via a frequency inverter in the range of 40 - 150% (rated speed=100%) is possible.
The above figures are standard. Other values on request.



Demand form

Questionnaire to perform curved belt conveyor 60C
